USRP 2974 High Performance Embedded SDR, 10 MHz-6 GHz, 160 MHz BW (785606-01)

The USRP-2974 is built on the LabVIEW reconfigurable I/O (RIO) architecture with an onboard Intel Core i7 processor running the NI Linux Real-Time OS. The USRP-2974 is a USRP Software Defined Radio Stand-Alone Device, meaning that you can target the onboard processor with LabVIEW Communications System Design Suite to deterministically perform processing. The USRP-2974 is also equipped with a GPS-disciplined 10 MHz oven-controlled crystal oscillator (OCXO) Reference Clock. You can prototype a range of advanced research applications that include stand-alone LTE or 802.11 device emulation; Medium Access Control (MAC) algorithm development; multiple input, multiple output (MIMO); heterogeneous networks; LTE relaying; RF compressive sampling; spectrum sensing; cognitive radio; beamforming; and direction finding. The registered trademark Linux® is used pursuant to a sublicense from LMI, the exclusive licensee of Linus Torvalds, owner of the mark on a worldwide basis.

Category: Tags: ,



Key product
  • Controller
    • System on module (SoM) : Congatec COM Express conga-TS170
    • CPU : Intel Core i7 6822EQ (2 GHz Quad Core)
    • Memory : SO-DIMM DDR4 16 GB
    • NVMe SSD : 500 GB
    • SFP+ : 10G ETH connection to the SoM
    • Cabled PCIe : PCIe Gen 2 x 4
    • MicroUSB : USB-to-UART to the SoM
    • RJ45 : 1G ETH host connection
  • FPGA and Baseband
  • FPGA : Kintex-7 XC7K410T
  • DRAM : 1 GB
  • Baseband analog-to-digital converter (ADC) resolution : 14 bit
  • Baseband digital-to-analog converter (DAC) resolution : 16 bit
  • Maximum I/Q sample rate : 200 MS/s
  • SFP+ : High speed serial link to one of the FPGA GTX transceivers



RF

  • Transmitter
  • Number of channels : 2
  • Frequency range : 10 MHz to 6 GHz
  • Frequency step : <1 kHz
  • Maximum output power (Pout), 10 MHz to 4 GHz : 50 mW to 100 mW (17 dBm to 20 dBm)
  • Maximum output power (Pout), 4 GHz to 6 GHz : 5 mW to 50 mW (7 dBm to 17 dBm)
  • Gain range : 0 dB to 31.5 dB
  • Gain step : 0.5 dB
  • Maximum instantaneous real-time bandwidth : 160 MHz



  • Receiver
  • Number of channels : 2
  • Frequency range : 10 MHz to 6 GHz
  • Frequency step : <1 kHz
  • Gain range : 0 dB to 37.5 dB
  • Gain step : 0.5 dB
  • Maximum input power (P in) : -15 dBm
  • Noise figure : 5 dB to 7 dB
  • Maximum instantaneous real-time bandwidth : 160 MHz
